Introduction
The HD50K-S is a very compact indoor/outdoor drill,with short drill mast for low headroom areas, and driven by electric motor, The rig is mounted with a high-torque rotator (with max. torque 1100 kgm for difficult drilling work, and with an expandable traction undercarriage on it for going through narrow places and doors, ideal for drilling jobs inside buildings, water drains and tunnels.
- Weight = 6.5 tons (14,300 lbs)
- Power = 43.5 kw (59 HP)
- Rotator max. torque = 11,000 Nm (7,953 ft.lb)
(Equipped with HR1100 rotator)
- Feed max. force = 7 tons (15,400 lb)
- Pullback max. force = 7 tons (15,400 lb)
Applications :
* DTH Drilling * Augering
* Rotary Drilling (Tricone Bits and Drag Bits)
* Coring
More Detail :
The HD50K-S is a very compact indoor/outdoor drill,with short drill mast for low headroom areas, and driven by electric motor, The rig is mounted with a high-torque rotator (with max. torque 1100 kgm for difficult drilling work, and with an expandable traction undercarriage on it for going through narrow places and doors, ideal for drilling jobs inside buildings, water drains and tunnels.
- Weight = 6.5 tons (14,300 lbs)
- Power = 43.5 kw (59 HP)
- Rotator max. torque = 11,000 Nm (7,953 ft.lb)
(Equipped with HR1100 rotator)
- Feed max. force = 7 tons (15,400 lb)
- Pullback max. force = 7 tons (15,400 lb)
Applications :
* DTH Drilling * Augering
* Rotary Drilling (Tricone Bits and Drag Bits)
* Coring
